EPIC-3-DL

  • SERIES: EPIC-3-DL
  • APERTURE: 3″
  • OPTICS: 36°, 54°
  • LUMENS: 700-1600 lm
  • CCT: 27K, 30K, 35K, 40K
  • CRI: 90+, 98+
  • RATING: New Construction, IC
  • LED SOURCE: Xicato

3″ IC Downlight

Recessed LED Downlight for Insulation Contact

FEATURES:

Luminaire designed for direct contact with insulation and certified airtight under ASTM E283. Three Four Five is the most extensive family of round or square luminaires for downlight, accent, wallwash and specialty applications.
– Up to 98 CRI, 1×2 Step MacAdam Ellipse
– Field-interchangeable internal ‘twist-and-lock’ reflector
– May be used in confidential spaces that must be soundproofed

EPIC-XTM-3DG

Xicato – No Lens Holder

EPIC-XTM-3DL

Xicato – w/Lens Holder

Lumen Output



700L
1000L
1200L
1300L
1600L

Color Temperature
2700K
3000K
3500K
4000K

Color Rendering
90+ CRI
98+ CRI


Technologies

Static White

Lighting Solution

Driver Options



DALI-EL

DALI-2 ‘Dim-to-Dark’



DIMTR

Tri-Mode Dimming™ (TRIAC, ELV & 0-10V)



DIM10

Flicker Free 1% DIM10 – 120 or 277V



ELDO10.1

0-10V ‘Dim-to-Dark’



ELDO10.1

0-10V ‘Dim-to-Dark’

Optical Distributions

36°

54°

Options



Emergency





Flanged



Reflector Finish Options

Semi Specular Clear

Slightly Diffused

Fully Diffused

Gold

Black

White
