- SERIES: IDM-STR1
- APERTURE: Up to 800L
- OPTICS: 10°, 15°, 20°, 30°, 45°, 55°, framing 20-35°, zoom 10-50°
- LUMENS: Up to 797 lm (optic dependent)
- CCT: 27K, 30K, 35K, 40K
- CRI: 90+, 97+
IDM-STR1
FEATURES:
IDM STRATA 1 is the integral dimmer version of the 10W STRATA 1 track head. The dimmer is built into the head, so it dims from a standard 120V TRIAC source with no separate control gear. The lens module sets the beam, and filters, snoots, grids, and barn doors add to the front as the job needs.
– Lens modules: fixed 10°, 15°, 20°, 30°, 45°, or 55°; zoom 10° to 50°; framing projector 20° to 35°
– 391 to 797 lm depending on optic; 97 CRI typical; 1 to 3 SDCM
– 2700K, 3000K, 3500K, or 4000K static white
– TRIAC dimming; 120V input
– 355° rotation and 90° tilt; black or white finish
– Glare control with snoots (half, medium, large), honeycomb, cross-baffle, and a 4-leaf barn door
– Add-ons: color, UV, diffusion, and gradient filters; oval, wall wash, and softening lenses
– Framing projector options: gobo holder, gobo patterns, and custom logo projection
– L70 at 50,000 hours or more; 5 year warranty
IDM-STR1
Integral Dimmer
Lumen Output
Up to 797 lm (optic dependent)
Color Temperature
2700K
3000K
3500K
4000K
Color Rendering
90+ CRI
97+ CRI
Technologies
Static White
Driver Options
Optical Distributions
10°
15°
20°
30°
45°
55°
framing 20-35°
zoom 10-50°
Options
Reflector Finish Options
Black
White
“
