STR1

SERIES: STR1
APERTURE: Up to 800L
OPTICS: 10°, 15°, 20°, 30°, 45°, 55°, framing 20-35°, zoom 10-50°
LUMENS: Up to 797 lm (optic dependent)
CCT: 27K, 30K, 35K, 40K, Tunable White
CRI: 90+, 97+

SKU: 0c6f0b8230dd Categories: 0-10V, 10D-24D, 10W track head, 120-277V, 25D-36D, 27K, 30K, 355 degree rotation, 35K, 37D-48D, 40K, 49D-60D, 80+, 90 degree tilt, 90+, 97+, Adjustable, barn door, Black, CASAMBI, color filter, CRI 97, cross baffle, DALI, diffusion filter, DIM10, Edison Price Lighting, framing projector, gobo, gradient filter, honeycomb, interchangeable lens, interchangeable optics, layered lighting control, lens module, logo projection, NONDIM, oval lens, Round, snoot, softening lens, Spot, Static White, STR1, STR1-LENS-FR25, STR1-LENS-FX, STR1-LENS-ZM, strada, STRATA, STRATA 1, Track, Track Head, track light, Track Mount, TRIAC, Tunable White, TWH, Up to 800L, UV filter, wall wash, White, zoom Tags: 0-10V, 010V, 10D-24D, 10D24D, 10W track head, 10Wtrackhead, 120-277V, 120277V, 25D-36D, 25D36D, 27K, 30K, 355 degree rotation, 355degreerotation, 35K, 37D-48D, 37D48D, 40K, 49D-60D, 49D60D, 80+, 90 degree tilt, 90+, 90degreetilt, 97+, Adjustable, barn door, barndoor, Black, CASAMBI, color filter, colorfilter, CRI 97, CRI97, cross baffle, crossbaffle, DALI, diffusion filter, diffusionfilter, DIM10, Edison Price Lighting, EdisonPriceLighting, framing projector, framingprojector, gobo, gradient filter, gradientfilter, honeycomb, interchangeable lens, interchangeable optics, interchangeablelens, interchangeableoptics, layered lighting control, layeredlightingcontrol, lens module, lensmodule, logo projection, logoprojection, NONDIM, oval lens, ovallens, Round, snoot, softening lens, softeninglens, Spot, Static White, StaticWhite, STR1, STR1-LENS-FR25, STR1-LENS-FX, STR1-LENS-ZM, STR1LENSFR25, STR1LENSFX, STR1LENSZM, strada, STRATA, STRATA 1, STRATA1, Track, Track Head, track light, Track Mount, TrackHead, tracklight, TrackMount, TRIAC, Tunable White, TunableWhite, TWH, Up to 800L, Upto800L, UV filter, UVfilter, wall wash, Wallwash, White, zoom

STRATA 1

10W track head with swappable lens modules: fixed 10° to 55°, zoom 10° to 50°, or framing projector 20° to 35°.

FEATURES:

STRATA 1 is a 10W track head built around interchangeable lens modules. The module sets the beam, so one fixture body covers focused accents, broader coverage, and shaped projection. Order the head and a lens module, then add filters, snoots, grids, or barn doors as the job needs.
– Lens modules: fixed 10°, 15°, 20°, 30°, 45°, or 55°; zoom 10° to 50°; framing projector 20° to 35°
– 391 to 797 lm depending on optic; 97 CRI typical; 1 to 3 SDCM
– 2700K, 3000K, 3500K, 4000K, or tunable white 2700K to 5700K
– Dimming and control: 0-10V, DALI, CASAMBI, TRIAC, or non-dim 277V; 120-277V input
– 355° rotation and 90° tilt; black or white finish
– Glare control with snoots (half, medium, large), honeycomb, cross-baffle, and a 4-leaf barn door
– Add-ons: color, UV, diffusion, and gradient filters; oval, wall wash, and softening lenses
– Framing projector options: gobo holder, gobo patterns, and custom logo projection
– L70 at 50,000 hours or more; 5 year warranty

STR1

Standard

SPEC SHEET

–

Lumen Output

Up to 797 lm (optic dependent)

Color Temperature

2700K

3000K

3500K

4000K

Tunable White

Color Rendering

90+ CRI

97+ CRI

Technologies

Tunable White
2700K-5000K

Static White

Driver Options

CASAMBI

DALI

DIM10

NONDIM

TRIAC

Optical Distributions

10°

15°

20°

30°

45°

55°

framing 20-35°

zoom 10-50°

Options

Emergency

Reflector Finish Options

Black

White

“
